WD-8140A

WD-8140A

★ 30 years production experience ★ 12 months quality warranty ★ CE certificate approved ★ All machines are tested well before shipping ★ Fast Delivery
Products Inquiry

Description

Technical Specifications:

ULTRA THIN PULLEY SCISSOR LIFT WD-8140A
Lifting capacity 4000kg
Lifting height Main1850mm  Jack450mm
Min.Height 190mm
Liting time 70-90s
Length of the platform 4465mm
Platform width 680mm
Motor power 3.0kw-380v or3.0kw-220v
Oil pressure Rating 24Mpa
Air pressure 0.6-0.8Mpa
Weight 2030kg

Characteristics:

1. This kind of scissor lift is hydraulic four wheel positioning, apply to various level of automobile of professional high-precision four wheel alignment and vehicle inspection, repair and maintenance.
2. the machine's mainly hydraulic components selected Italy, Germany high quality imported parts assembly, adopting dual gear, hydraulic and electrical tripling protection, safe, reliable, synchronous stable running.
3. Oil cylinder with upper return oil, prevent oil cylinder rust.
